Siemens 9410 Series User Manual

Communications 9410 series
kVA sd mx rec kVA sd mx del-
rec
kVA sd del kVA sd rec kVA sd del-rec kWh del
kWh rec kWh del-rec kVARh del kVARh rec kVARh del-rec kVAh del
kVAh rec kVAh del-rec
The following meter information is always provided by default and cannot be
configured:
Voltsmode Model number
Serial number Device name
Firmware version MIB version
If you change your meter’s default values you must modify the custom MIB file to
reflect the new values.
Changing your meter’s default SNMP configuration assumes that you have an
advanced understanding of ION architecture, SNMP, and the communications network
and power system that your meter is connected to.
See the ION Reference, available from www.usa.siemens.com/pds, for detailed
information on the SNMP Mapping module.
Configuring your SNMP MIB file
You must configure your MIB file if you have modified the default SNMP information
provided by the meter in order for the MIB file labels to reflect the modified values.
Download the ION MIB file from www.usa.siemens.com/pds.
NOTE: You should only configure the variable name and description. Changing
other fields in your MIB file may cause the client software to report problems or
return errors when trying to retrieve or view parameters.
The variable name must conform to the following rules:
• The first character must be a letter.
• The first character must be lower case.
• The name must not contain any special characters such as *, ?, &.
• The name must not contain spaces.
1. Open your meter’s MIB file in a text editing program (such as Notepad).
2. Update the variable name and description so they match the meter values
connected to the SNMP Mapping module.
3. Save your meter’s MIB file. Make sure you keep the original file extension of .MIB.
This example shows an original and an updated OID entry in an MIB file, where the
default meter value of voltage line-to-neutral phase A is modified in the meter’s SNMP
Mapping module and is now connected to voltage line-toneutral phase C.
Original OID entry
Vln_a OBJECT-TYPE
SYNTAX DisplayString (SIZE (0. . 255))
ACCESS read-only
STATUS mandatory
DESCRIPTION “Host Meter Voltage Line A to Neutral Units = V (Volts)” ::= { Siemens Industry 34 }
7EN05-0336-03 89
