Emergency power supply
100
Building Technologies 008725_h_en_--
Fire Safety & Security Products 06.2011
36.2 Quiescent current table
Quiescent current during battery operation (24 V)
As basis for individual emergency current calculation
The current of the 5 V supply is included in these values
Component Quiescent current at 24 V DC (typical) Extra current during alarm
B1F120 / B2F020 /
B2F040 / B2F060
0 0
B2Q191/B1Q101 33 mA max. 1 A for duration of print process
B3Q321 17 mA + 5 mA
B3Q440 25 mA + 10 mA
B3Q6../566 100 mA with inactive lighting (active = + 200 mA) + 230 mA
B3Q580 20 mA + 160 mA
B3Q590/595 18 mA + 167 mA
B3R051 22 mA all LEDs inactive + 2 mA per activated LED
E3C011 50 mA 0
E3G050 10 mA all relays inactive + 11 mA per activated relay
E3G060 25 mA all control lines connected + 23 mA per activated control line, no ext. load
E3G070 25 mA 'Horn' control lines terminated + 34 mA without external load (horns, etc.)
E3G080 35 mA all lines terminated + 25 mA without external load (valves, horns, etc.)
E3G091 0 all channels inactive + 9 mA per activated channel
E3G110 0 during degraded mode and alarm active only + 15 mA per activated channel during degraded
mode
E3H021 85 mA 0
E3I020 25 mA 0
E3L020 22 mA + .. mA depending on what is activated
E3L030 18 mA + 40 mA no external load (FBF, HM, FSK)
E3M060 155 mA (=120 mA + 0.7 mA per MS9i element) 1) 0
E3M071 115 mA (=50 mA + 0.5 mA per D bus device) 1)
(no external 24 V loading)
0
E3M171 70 mA with 32 detectors (=50 mA without detectors + 0.5 mA
per D bus device) 1)
0
E3M080 85 mA 37 mA + 6 mA per terminated line + 10 mA per line in alarm
E3M111 210 mA (=50 mA + 0.31 mA per D bus device) 1)
(A+ no external 24 V loading)
0
E3M120 8.5 mA +1.3 mA for each detector address 0
E3M141 80 mA without devices (+0.47 mA per load factor) + .. mA depending on what is activated
E3X102/103 120 mA 'Horn' control line terminated + 50 mA without external load (horns, etc.)
K1D012 25 mA 0
K1D081 50 mA 0
K1D121 50 mA 0
K1D140 25 mA 0
K1H022 20 mA (all LEDs and optocouplers active) 0
K3G060 6 mA + 3 mA per relay
K3R072 22 mA + 2 mA per activated LED (-> F50F410)
0 per activated relay (-> K3G060)
NK823x 190 mA 0
Z3B171 0 + 27 mA per activated relay
E3I040 15 mA no external 24 V loading 0
K3I050 15 mA + 0 mA or 4 mA per activated LED
K3I090 50 mA 0
K3I110 24 mA max. 184 mA all rel. activated including service LED + 10 mA per activated relay
+ 0.5 mA per input with closed contact
1) only valid for devices with APMK = 1 / IMK = 1 (value for devices > 1 multiplied). DC1151 example: 0.5 mA x 12 = 6 mA
