Configuration sheets
113
Building Technologies 008725_h_en_--
Fire Safety & Security Products 06.2011
43 Configuration sheets
The following pages are intended as templates for copying or can be used as a
suggestion for a country-specific tool.
The system-specific configuration (use of installation space, number and type of
components, etc.) is entered on these sheets.
List of configuration sheets:
Configurations with AlgoPilot B3Q... as main CPU
– CI1142 in housing H38... (flat) –> page 114
– CI1142 in housing H38... (deep) –> page 114
– CI1142 in housing H47... –> page 116
Configurations with E3X10. as main CPU
– CC1142/43 in housing H47... –> page 117
– CC1142/43 in housing H47...(with extra power supply) –> page 118
– CC1142/43 in housing H67...(standard) –> page 119
– CC1142/43 in housing H67...(with 2 sets of batteries) –> page 120
– CC1142/43 in housing H67...(with extended connection panel) –> page 121
Configurations with upright cabinet
– CS1140 in housing H98G600 –> page 122
Configurations of AlgoPilot B3Q... operating units
– CT1142 –> page 123
Configurations of display & operating device
– B3Q580/590/595, B3Q321, B3Q440, B3R051 etc. –> page 124
Components positioned externally
– K3I110, K3I050, K3R072, K3G060 etc. –> page 124
Printer configuration
– B2Q191, B1Q101 –> page 125
