AlgoPilot B3Q... operating terminal
50
Building Technologies 008725_h_en_--
Fire Safety & Security Products 06.2011
17.1.4 Components and labeling kits for B3Q6../566
AlgoPilot operating terminal
B3Q661 A5Q00020708 'International' operating terminal Operating unit and main CPU at the same time
B3Q681 S54371-F12-A1 'Nordic' operating terminal ”
B3Q686 S54371-F11-A1 'CH' operating terminal ”
B3Q566 S54371-F13-A1 'China' operating terminal ”
Flash program file for operating unit (CT....)
CTX00xxx (PSP) 'International' Flash program file for B3Q661, B3Q68x
CTYT1xxx (PSP) 'China simple' Flash program file for B3Q566
CTYTExxx (PSP) 'China traditional' Flash program file ”
CTYTLxxx (PSP) 'Korea standard' Flash program file ”
CTYT5xxx (PSP) 'Thailand' Flash program file ”
Flash program file for parallel operating unit (CA....)
CAX00xxx (PSP) 'International' Flash program file for B3Q661, B3Q68x
CAYT1xxx (PSP) 'China simple' Flash program file for B3Q566
CAYTExxx (PSP) 'China traditional' Flash program file ”
CAYTLxxx (PSP) 'Korea standard' Flash program file ”
CAYT5xxx (PSP) 'Thailand' Flash program file ”
Flash program file for operating unit and CPU at the same time (CI....)
CIX00xxx (PSP) 'International' Flash program file for B3Q661, B3Q68x
CIYT1xxx (PSP) 'China simple' Flash program file for B3Q566
CIYTExxx (PSP) 'China traditional' Flash program file ”
CIYTLxxx (PSP) 'Korea standard' Flash program file ”
CIYT5xxx (PSP) 'Thailand' Flash program file ”
Available labeling kits (if no designation strips are available –> use templates from document 006516)
Z5B415 5706530001 'Portuguese' labeling kit
Z5B435 5706660001 'Dutch' labeling kit
Z5B505 5706790001 'Turkish' labeling kit
Z5B525 5706820001 'German CH' labeling kit
Z5B535 5706950001 'German D' labeling kit
Z5B545 A5Q00004396 'Italian CH' labeling kit
Z5B555 5707050001 'Italian I' labeling kit
Z5B565 5707180001 'French CH' labeling kit
Z5B585 5707210001 'French F' labeling kit
Z5B595 5707340001 'Danish' labeling kit
Z5B605 5707470001 'Finnish' labeling kit
Z5B615 5707500001 'Norwegian' labeling kit
Z5B625 5707630001 'Swedish' labeling kit
Z5B635 5707760001 'English' labeling kit
Z5B645 5707890001 'English GB' labeling kit
Z5B665 5707920001 'Spanish' labeling kit
Z5B685 5706400001 'Hebrew' labeling kit
Options
H26T030 5705300001 Plexi glass doors for AlgoPilot Including installation options
Z3S200 5703490001 Key switch module for AlgoPilot (KABA) For accessing operating unit
V2G050 5706110001 Cable for 9 V lithium battery To fault display should the mains and emergency power
battery fail
B3R051 4905130001 '2x24 displays' parallel display
Options for RS232 interface and PSA interface board to all AlgoPilots
E3I020 4602390001 RS232 plug-in module To connect a printer –> see page
90
Z1B020
4759070001 Installation options for E3I020 Compulsory for installation of E3I020 on rear of AlgoPilot
B3Q...
F20A020 4763170001 20-wire 0.165 m 'Micro' flat cable
E3I020 –> B3Q.. connection if E3I020 is on rear of
B3Q...
K3I090 5108200001 PSA interface board For connecting PSA/pager and internal/external printer –
> see page 94
Z1B060
5259840001 Installation options for K3I090 Compulsory for installation of K3I090 on rear of AlgoPilot
B3Q...
Options for E3I040 to connect to I bus of AlgoPilot CT11 in housing H28G200
E3I040 4993100001 LON plug-in module Converter between I bus and LON bus
Z1B070 A5Q00001720 Installation options for E3I040 Compulsory for installation of E3I040 in housing
H28G200
