26.3 "Interactive" Ex detector line
 Number of addresses: Max. 32, –> limitations for certain device types 1)
 T-branches possible
1
S
tub lin
e
D-Bus max. 32 addresses / 70 
DOT1151A-Ex DT1151A-Ex
SB3
DM115x-Ex
E3M171
DF1151-Ex
1)
Dxx115x
Explosion hazard area
non-Explosion
hazard area
the software can not proof wheter or not Non-Ex-
detectors are in the explosion hazard area
DT1151A-Ex
DOT1151A-Ex
Dxx115x
Dxx115x
1) For details, see documents 001508 and 1204
26.4 'CBA8000/TS9000' detector line
 Number of addresses per line: Max. 119
1
2
4
3
4
Loop lines
CBA-Bus max. 119 addresses / 30 
E3M120
CBA8000/TS9000CBA8000/TS9000 CBA8000/TS9000
CBA8000/TS9000
