31 Remote transmission (conforming to EN54-2)
Most fire detection installations are connected to a remote transmission. In alarm
status (alarm level 2) the fire detection system activates the remote transmission
device (RT device).
Remote transmission device
– Single-channel (alarm + fault) or multi-channel (multi-criteria alarm)
– Block/release via AlgoPilot
Connections
– Via outputs and special inputs/outputs from central plug-in module E3X10. or
control panel module E3G070
– Via remote transmission interface E3G091 if 'Multiple criteria' are used
– Via control plug-in module 'VdS’ E3L030' 'Main detector' (ÜE) (Germany)
If the E3L030 is present, the ÜE MUST be used.
– Can be used spanning several CPUs (several CPUs linked to the same RT de-
vice)
I-Bus
E3G070
A
lgoPilot
B3Q... (CPU)
I-Bus
Interfacing via E3G070
K2
E3X10.
CPU
I-Bus
Interfacing via E3X10.
K2
RT-devices
Alarm Fault
E3X10./E3G070
Interfacing via E3G091
CC11
CI11
Q1.........Qx
E3G091
K2
CPU
Interfacing via E3L030
E3L030
RT
CC11
CI11
E3....
CC11 CI11
RT-devices
RT-devices
Alarm Fault
FDCIO223
Fault
FDCIO223
Alarm
