Siemens AlgoRex CS1140 - 12 CI1142 in Housing H38

CI1142 in housing H38... (flat)
31
Building Technologies 008725_h_en_--
Fire Safety & Security Products 06.2011
12 CI1142 in housing H38... (flat)
520
602
88
100*
H38G220
H23B010
Z1K030
H23B040
B2F020
FA2005-A1
Z3I380
B3Q...
B3Q...
H38G220:
Set with
- cabinet
- door
- module chassis
- earth terminals
* incl. projecting door hinges
Connection
for periphery
Module
Component
of
Z3I470
 Compact control panel in flat design
 Connected directly to the plug-in modules
 Only a very limited selection of options can be fitted
 Batteries: 2x 12 V/15 Ah
 Operating unit fitted in front (serves as main CPU at the same time)
 Additional display devices cannot be fitted
 Doors hinged on right, can be locked with 2 Allen screws
H38G220
51
31
A
B
45.1 .. 45.3
55.1 .. 55.3
58
47
57
38
28
48
Module chassis
view 'Modules'
Cabinet front view
Module chassis view
'Fire control installations relay'
E3M060/071/171/120
and E3C011 are
possible at positions
28+38
Note:
not
absolutely essential
recommended
space allocation
Comply with max.
permissible number
of 'nodes' +
I-Bus modules!
-> Details see chapter
Outline quantities
Important:
View A View B
Mains
acce-
ssories
Terminal block
and holder
containing in
cable set Z3I470
Mounting of
E3C011:
21
EMC Precaution:
not be
Position 57 must
fit with either
E3I040 or E3G080
modules
E3I020 Z1K030
E3... Z1K030
E3... Z1K030
E3... Z1K030
E3G070 Z1K030
E3C011 Z3I470
(Battery 12 V)
FA2005-A1
B2F020 AC-DC converter
Z3B171 Z3B171 Z3B171
Z3B171 Z3B171 Z3B171
(Battery 12 V)
FA2005-A1
 For details of H38… housing –> see section 20
