Siemens AlgoRex CS1140 User Manual

Line plug-in modules
70
Building Technologies 008725_h_en_--
Fire Safety & Security Products 06.2011
26.7 'Collective' detector line
 All detectors within a line have the same collective address (OBJECT)
 Depending on application, end-of-line by means of transzorb diode or EOL22
(Ex)
 Number of detectors per line:
– DS11 detectors: Max. 25
– MS6/7/9/24: According to individual load factor 1)
 For detector types that can be activated, see compatibility overview (document
001260)
1
8 Stub lines
DJ1192
DO110x
DT110x
F716
F910
AT50 ATAN50
DM1101
SB3
24VDC
E3M080
2
3
8
mixed detector series
only with E3X100 permissible
see document 1204 and UP 109
Restriction:
4
DT110x
DO110x
SB2
5
for details see document 1204
'new' detector series
(DS11, MS9, MS716)
line termination :Transzorb 20 V
line resistance :max.150

'old' detector series
(MS712, MS6)
line termination EOL22
line resistance :max.250

'old' detector series
DC1192
E
x
DO1101-Ex
DT1101-Ex
Ex
DO1101-Ex
DT1101-Ex
DO110x
no detectors permissible
DF1101-Ex
DF1101-Ex
R970
EOL22 (Ex)
Line termination
EOL22 (Ex)
DLO1191
DF1191/92
DBZ1197A
DMA1103
DM1101
DMA1103
DM1101
DMA1103
DLR11
Line termination
1) For details, see document 825 for MS6/7/9, for DS11 collective 001508
