Commissioning
105
Building Technologies 008725_h_en_--
Fire Safety & Security Products 06.2011
39 Commissioning
 For details, see document 004594
The CS1140 fire detection system is designed for a rational installation setup.
Connection to the control panel may be undertaken by experts without special
training (e.g. external electricians). Coordinated construction management is
however still indispensable. A specially trained person with a maintenance PC is
needed for commissioning (service technician).
Procedure
Preparatory work (by designer / construction manager)
 Plan system
 Produce connection diagram for control panel
 Supply control panel housing, component carrier and connection panel
 Instruct assembly staff
Assembly / connection of control panel (by electrician)
 Installation of component carrier at intended location
 Connect lines to detectors, alarm devices etc. on connection panel according to
diagram
 Check detector supply network up to and including connection panel in control
panel
Commissioning (by service technician)
 Fit board holder, connection cable, etc.
 Insert electronic plug-in modules and attach I bus
 Produce logical structure of system or adopt from designer
 Define system-specific functions
 Define user text
 Set parameters for detectors using special evaluation algorithms
 Detector localization
 Check control panel and detectors
 Download system data
