Siemens AlgoRex CS1140 User Manual

Planning conforming to EN54-2
21
Building Technologies 008725_h_en_--
Fire Safety & Security Products 06.2011
8 Planning conforming to EN54-2
8.1 Binding functions
When planning the fire control panel, ensure that binding functions are planned
correctly in accordance with standard EN54-2 (e.g. detection, alarming, remote
transmission).
No more than one binding function may fail in the event a simple fault on fire con-
trol panels with more than 512 detectors. When using bus-based I/O modules in
particular, ensure that binding functions are not concentrated on one line but
spread over various lines. We would highly recommend using loop technology.
8.2 Options with requirements
The following options with requirements are available on fire detection system
Algorex CS1140. The chapter numbers belong to EN54-2.
Indications:
7.13 Alarm counter
8.3 Fault signals from points
8.4 Total loss of the power supply
Controls:
7.11 Delays to outputs
7.12.2
Dependencies on more than one alarm signal Type B
9.5 Disablement of addressable points
10
Test conditions
Outputs:
7.8 Output to fire alarm devices
7.9.1 Output to fire alarm routing equipment
7.10.1
Outputs to fire protection equipment Type A
7.10.2 Outputs to fire protection equipment
Type B
7.10.3 Outputs to fire protection equipment
Type C
8.9 Output to fault warning routing equipment
Inputs:
7.9.2 Alarm confirmation input from fire alarm routing equipment
7.10.4 Fault monitoring of fire protection equipment
8.3 Outputs for triggering fire controls
In accordance with EN54-2, the state of the fire protection equipment (fire controls)
of types B (without confirmation) and C (with confirmation) must be displayed using
separate light-emitting display elements. The freely programmable LED on the
B3Q661/B3Q681/B3Q686 can be used for this purpose. The active state must be
displayed separately for fire controls which are controlled and those with confirma-
tion, using one red LED in each case. If type B and C fire controls occur at the
same time or if freely programmable LEDs are used elsewhere, a parallel display
B3R051 should be provided.
