Siemens AlgoRex CS1140 User Manual

CC1142/43 in housing H47...
37
Building Technologies 008725_h_en_--
Fire Safety & Security Products 06.2011
15 CC1142/43 in housing H47...
Z3I350
H47G601/611:
Set with
- door
- frame
- module chassis
- terminal blocks
- mains terminals
- battery supporting plate
- relay rail
can be plugged into
connection block
B3R051
Module
B3Q321
H23B040
H23B010
Control terminal
installed separately
300
735
434
H47G601
H47G611
B2F020
E3X1..
FA...
FA...
B3Q...
Z1I060
Z1I020
Z1I030
Z1I100
or
or
or
 Removable system control panel
 With separate main CPU (E3X10.)
 Separate connector panel (not recommended without connector panel)
 Space for options
 Batteries: either 2x 12 V/24 Ah or 2x 12 V/38 Ah
 Operating unit usually remote (can be fitted in doors)
 Doors hinged on right with lock (DOM type)
E3I020 if used,
mount at position 32!
Note:
- one or two connection cables Z1I060, Z1I020,
Z1I100 or Z1I030 are required for each module:
One Z3I330 terminal block has space for:
either
- 2x Z1I030 or
- 8x Z1I060 or
- 4x Z1I020, 4x Z1I100 or
- 1x Z1I030 and 2x Z1I020
1) Protection elements, Modem filter
Cable duct
Cable duct
21
52 55
34 35 36 37
45 47 48
33
4442 43
31
32
Terminal block for
E3X10. containing in
cable set Z3I350+
2 x Z1I030
Mounting of E3X10.:
1)
If Z3I041 or B3P020
is used, on Pos. 36
E3M060/071/171/120
and E3C011
possible!
not
25
Z3B171
Z3B171
Z3B171
Z3B171
Z3B171
Z3B171
Z3B171
Z3B171
22 23 24
Z3I330 (Diverse)
Z3I330 (Lines) Z3I330 (E3X10.)
B2F020
AC-DC converter
H47G601 or H47G611
E3I020 Z1I030 E3L020 Z1I030 E3G050 Z1I030
E3.... Z1I... E3.... Z1I...
E3.... Z1I...
E3X10. + 2 x Z1I030 + Z3I350
E3M... Z1I... E3M... Z1I... E3M... Z1I... E3M... Z1I...
E3H020 + 2x Z1I030
(Battery 12 V)
or
FA2006-A1
FA2007-A1
Important:
Comply with max. permissible number
of 'nodes' + I-Bus modules!
-> Details see chapter ‘Outline quantities’
absolutely essential
recommended space allocation
Supplied with cabinet set H47G601/611
Line modules
LON module
Control modules
Extinguishing modules
Interfaces
Mains
terminals
Fire control relay
Connection
panel
Modules
Batteries
(Battery 12 V)
or
FA2006-A1
FA2007-A1
 For details of H47… housing –> see section 21
 For details of protective elements, modem filter –> see section 38, 29
