Siemens AlgoRex CS1140 - Extra Power Supply in Second H47 Housing

CC1142/43 in housing H47...
39
Building Technologies 008725_h_en_--
Fire Safety & Security Products 06.2011
15.1 Extra power supply in second H47 housing
52 55
41
31
51
21
32 35
22 25
Supplementary power
supply on module chassis
H47E110 using three
H15Z300 battery
support plates
Application example:
- Place housings next to or on top of each other (do not install at a
distance)
- the additional E3C011 are not used as I-Bus equipment
- use one Z3I870 cable set per supplementary power supply
Remarks:
H47E110 and H47T101
Housing set H47G611
or H47E100 and H47T111
Cable duct
Cable duct
21
52 55
34 35 36 37
45 47 48
33
4442 43
31
32
Mains
terminals
1)
25
Fire control relay
22 23 24
Z3I330 (Diverse)
Z3I330 (Lines) Z3I330 (E3X10.)
B2F020
AC-DC Wandler
H47G601 or H47G611
E3I020 Z1I030 E3L020 Z1I030 E3G050 Z1I030
E3.... Z1I... E3.... Z1I...
E3.... Z1I...
E3X10. + 2 x Z1I030 + Z3I350
E3M... Z1I... E3M... Z1I... E3M... Z1I... E3M... Z1I...
E3H020 + 2x Z1I030
(Battery 12 V)
or
FA2006-A1
FA2007-A1
(Battery 12 V)
or
FA2006-A1
FA2007-A1
max. 8
H47E110
B2F020
H15Z300 H15Z300
(Battery 12 V)
or
FA2006-A1
FA2007-A1
H15Z300 H15Z300
H15Z300 H15Z300
E3C011 Z3I870
E3C011 Z3I870
E3C011 Z3I870
(Battery 12 V)
or
FA2006-A1
FA2007-A1
(Battery 12 V)
or
FA2006-A1
FA2007-A1
(Battery 12 V)
or
FA2006-A1
FA2007-A1
(Battery 12 V)
or
FA2006-A1
FA2007-A1
(Battery 12 V)
or
FA2006-A1
FA2007-A1
 H47G611 or H47E100 and H47T111 housing kit –> for details, see section 21
 Details of principle wiring for power supply –> see chapter 35
Options needed
H47E110 4761840001 Component carrier empty
H47T101 4953560001 Housing frames + doors without cut-out
B2F020 A5Q00025281 Converter 115/230 V AC ->29.6 V DC, 6 A
E3C011 5054790001 Plug-in battery charging module
H15Z300 4761970001 Retaining plate for batteries For the second and other sets of batteries
FA2006-A1 A5Q00019356 12 V/24 Ah battery
FA2007-A1 A5Q00022897 12 V/38 Ah battery
Z3I870 4969440001 Cable kit For additional power supply
