Fire & Security Products
Siemens Building Technologies Group
01.1999
Checking completeness of allocations
Before the configuration data is loaded into the CC11/CI11 station, it must be ensured that
all of the physical structure devices are linked to a logical element and localized, and that
all devices in the localization structure are allocated to an element.
During partial commissioning, it can of course happen that elements/devices are present
in the configuration but have not yet been localized. This results in the following mes-
sages following a successful download:
NOTIFICATION ’...IMPAIRED’ for every non-localized device
Because this is an element message, it only appears if the relevant device is already
linked to a logical element
FAULT Message ’Configuration control unit’
This message always appears as soon as at least one physical device is not local-
ized (even if this device is not linked to an element)
If these messages are not desired, the physical device may not be input before the local-
ization is also carried out.
Check for completeness:
Start the SWE11
Load the CC11/CI11 main control unit data file
No elements in the logical structure may have a prefix (’*’ or ’>’)
The prefix ’*’ means that the element is not linked to a physical device and has not yet
been localized
The prefix ’>’ means that the element is linked to a physical device but has not yet
been localized
No device in the physical structure may have a prefix (’*’ or ’>’)
The prefix ’*’ means that the device is not linked to a logical element and has not yet
been localized
The prefix ’>’ means that the device is linked to a logical element but has not yet been
localized
No devices in the localization structure may have a prefix (’*’ or ’?’)
The prefix ’*’ means that the localization data for the device has not yet been allo-
cated to a logical element/physical device
The prefix ’?’ means that the localization data for the device is invalid
