Siemens CPU 410-5H Process Automation User Manual

Properties and technical specifications of CPU 410 SMART
15.2 Technical specifications of the CPU 410 SMART; (6ES7 410-5HN08-0AB0)
CPU 410-5H Process Automation/CPU 410 SMART
206 System Manual, 10/2013, A5E32631667-AA
6ES7410-5HN08-0AB0
•
Backup battery time, max.
Covered with the conditions and effects described in the
Module Data manual
•
Feed of external backup voltage to the CPU
No
CPU processing times
CPU speed
450 MHz; multiprocessor system
PCS 7 process objects
800; only System Expansion Card PO800 can be used
Average processing time of PCS 7 typicals
110 µs; with APL typicals
Process tasks, max.
4; can be set individually from 200 ms to 5 s
CPU blocks
DB
Number, max.
16000; number range: 1 to 16 000 (= instances)
FB
Number, max.
8000; number range: 0 to 7999
FC
Number, max.
8000; number range: 0 to 7999
OB
Number of free-cycle OBs
1; OB 1
Number of time
-of-day interrupt OBs 8; OB 10-17
Number of cyclic interrupt OBs
4; OB 32-35
Number of DPV1 interrupt OBs
3; OB 55-57
Number of restart OBs
2; OB 100, 102
Number of asynchronous error OBs
9; OB 80-88
Number of synchronous error OBs
2; OB 121, 122
Data areas and their retentivity
Retentive data area, total
Total work and load memory (with backup battery)
Address range
I/O address range
Inputs
16 KB
Outputs
16 KB
of those distributed
•
DP interface, inputs
1536 bytes; up to 1500 IO
•
DP interface, outputs
1536 bytes; up to 1500 IO
•
PN interface, inputs
1536 bytes; up to 1500 IO
•
PN interface, outputs
1536 bytes; up to 1500 IO
Digital channels
Inputs
36864, max.
Outputs
36864, max.
Analog channels
Inputs
2304, max.
Outputs
2304, max.
