Properties and technical specifications of CPU 410 SMART
15.2 Technical specifications of the CPU 410 SMART; (6ES7 410-5HN08-0AB0)
CPU 410-5H Process Automation/CPU 410 SMART
System Manual, 10/2013, A5E32631667-AA
211
6ES7410-5HN08-0AB0
UDP
Yes; via integrated PROFINET interface and loadable FBs
•
Number of connections, max.
118
•
Data length, max.
1472 bytes
Number of connections
Total
120
S7 message functions
Number of stations that can be logged on for message
functions, max.
119; max. 119 with Alarm_S and Alarm_D (OPs); max 12 wit
Alarm_8 and Alarm_P (e.g., WinCC)
Alarm_8 blocks
Yes
•
Number of instances for Alarm_8 and S7 communication
blocks, max.
10000
•
Pre-assigned, max.
10000
Process control messages
Yes
Test and commissioning functions
Block status
Yes
Single-step
Yes
Number of breakpoints
4
Monitor/modify
Status/modify tag
Yes
Tags
Inputs/outputs, bit memory, DB, I/O inputs/outputs, timers,
counters
Number of tags, max.
70
Diagnostics buffer
Available
Yes
Number of entries, max.
3200
Service data
Readable
Yes
EMC
Emission of radio interference according to EN 55 011
Limit class A, for use in industrial areas
Yes
Limit class B, for use in residential areas
No
Configuration
Know-how protection
User program/password security
Yes
Block encryption
Yes; using S7-Block Privacy
Dimensions
Width
50 mm
Height
290 mm
Depth
219 mm
Slots required
2
Weights
Weight, approx.
1.1 kg
