Siemens CPU 410-5H Process Automation User Manual

Properties and technical specifications of CPU 410 SMART
15.2 Technical specifications of the CPU 410 SMART; (6ES7 410-5HN08-0AB0)
CPU 410-5H Process Automation/CPU 410 SMART
210 System Manual, 10/2013, A5E32631667-AA
6ES7410-5HN08-0AB0
4. Interface
Type of interface
Plug-in synchronization module (FOC)
Plug
-in interface modules Synchronization module 6ES7960-1AA06-0XA0 or
6ES7960-1AB06-0XA0
5. Interface
Type of interface
Plug-in synchronization module (FOC)
Plug
-in interface modules Synchronization module 6ES7960-1AA06-0XA0 or
6ES7960-1AB06-0XA0
Protocols
PROFINET IO
Yes
PROFINET CBA
No
PROFIsafe
No
PROFIBUS
Yes
Protocols (Ethernet)
TCP/IP
Yes
Other protocols
AS-i
Yes; via add-on
MODBUS
Yes; via add-on
Foundation Fieldbus
Yes; via DP/FF link
Communication functions
PG/OP communication
Yes
•
Number of connectable OPs without message processing
119
•
Number of connectable OPs with message processing
119; when using Alarm_S/SQ and Alarm_D/DQ
Data record routing
Yes
S7 routing
Yes
S7 communication
Supported
Yes
As server
Yes
As client
Yes
User data per job, max.
64 KB
User data per job (consistent), max.
462 bytes; 1 variable
Open IE communication
TCP/IP
Yes; via integrated PROFINET interface and loadable FBs
•
Number of connections, max.
118
•
Data length, max.
32 KB
•
Several passive connections per port, supported
Yes
ISO
-on-TCP (RFC1006) Yes; via integrated PROFINET interface or CP 443-1 and
loadable FBs
•
Number of connections, max.
118
•
Data length, max.
32 KB; 1452 bytes via CP 443-1 Adv.
