Properties and technical specifications of CPU 410 SMART
15.2 Technical specifications of the CPU 410 SMART; (6ES7 410-5HN08-0AB0)
CPU 410-5H Process Automation/CPU 410 SMART
System Manual, 10/2013, A5E32631667-AA
209
6ES7410-5HN08-0AB0
Media redundancy
Supported
Yes
Changeover time at line interruption, typ.
200 ms
Number of nodes on the ring, max.
50
Functionality
PROFINET IO controller
Yes
PROFINET IO device
No
PROFINET CBA
No
Open IE communication
Yes
Web server
No
PROFINET IO controller
Transmission rate, max.
100 Mbps; full duplex
Number of connectable IO devices, max.
48
Number of connectable IO devices for RT, max.
48
•
of which in line, max.
48
Shared device, supported
No; but can be used in S7 framework
Prioritized startup supported
No
Enabling/disabling of IO devices
No
Hot swapping of IO devices (partner ports), supported
No
Device replacement without removable medium
Yes
Send clocks
250 µs, 500 µs, 1 ms, 2 ms, 4 ms
Update time
250 µs to 512 ms, minimum value depends on the amount
of configured user data and the configured operating mode
or redundancy mode
Services
•
PG/OP communication
Yes
•
S7 routing
Yes
•
S7 communication
Yes
•
Open IE communication
Yes
Address range
•
Inputs, max.
1536 bytes; up to 1500 IO
•
Outputs, max.
1536 bytes; up to 1500 IO
•
User data consistency, max.
1024 bytes
Open IE communication
Open IE communication, supported
Yes
Number of connections, max.
118
Local port numbers used by the system
0, 20, 21, 25, 102, 135, 161, 34962, 34963, 34964, 65532,
65533, 65534, 65535
Keep Alive function supported
Yes
3. Interface
Type of interface
integrated
Physics
RJ45 (only for service)
