Siemens CPU 410-5H Process Automation User Manual

Properties and technical specifications of CPU 410 SMART
15.2 Technical specifications of the CPU 410 SMART; (6ES7 410-5HN08-0AB0)
CPU 410-5H Process Automation/CPU 410 SMART
208 System Manual, 10/2013, A5E32631667-AA
6ES7410-5HN08-0AB0
DP master
Number of connections, max.
32
Transmission rate, max.
12 Mbps
Number of DP slaves, max.
48
Services
•
PG/OP communication
Yes
•
Routing
Yes
•
Global data communication
No
•
S7 basic communication
No
•
S7 communication
Yes
•
S7 communication, as client
Yes
•
S7 communication, as server
Yes
•
Support for constant bus cycle time
No
•
Isochronous mode
No
•
SYNC/FREEZE
No
•
Activation/deactivation of DP slaves
No
•
Direct data exchange (cross-traffic)
No
•
DPV1
Yes
Address range
•
Inputs, max.
1536 bytes; up to 1500 IO
•
Outputs, max.
1536 bytes; up to 1500 IO
User data per DP slave
•
User data per DP slave, max.
244 bytes
•
Inputs, max.
244 bytes
•
Outputs, max.
244 bytes
•
Slots, max.
244
•
Per slot, max.
128 bytes
2. Interface
Type of interface
PROFINET
Physics
Ethernet RJ45
Electrically isolated
Yes
Integrated switch
Yes
Number of ports
2
Automatic determination of transmission rate
Yes; Autosensing
Autonegotiation
Yes
Autocrossing
Yes
Change of the IP address at runtime, supported
No
Number of connection resources
120
