229/248
Building Technologies Division Basic documentation LMV36... CC1P7544en
Infrastructure & Citiies Sector 29 Parameter list LMV36... 25.09.2013
Par. Parameter Number of Type Edit Value range Resolution Default Password level
no. LMV36... elements Min Max setting
Index 1 = air
922 Incremental position of actuators
Index 0 = fuel
Index 1 = air
2 Std_s16 Read only -50° 150° 0.01° 0° Info / Service
935 Absolute speed 1 Std_u16 Read only 0 6553.5 0.1 0 SO
936 Standardized speed 1 Std_s16 Read only -200% 200% 0.1% 0% Info / Service
942 Active load source
1 = output during curve settings
2 = manual output
3 = default output via building automation
4 = default output via analog input
5 = external load controller via contacts
1 Selection Read only 0 255 1 0 SO
945 Actual fuel
0 = fuel 0
1 = fuel 1
1 Std_u8 Read only 0 255 1 0 Info / Service
947 Results of contact release (bit-coded)
Bit 0.0 = 1: pressure switch-min
Bit 0.1 = 2: pressure switch-max
Bit 0.2 = 4: pressure switch valve proving
Bit 0.3 = 8: pressure switch air pressure switch
Bit 0.4 = 16: internal fuel selection 1
Bit 0.5 = 32: load controller ON
Bit 0.6 = 64: internal fuel selection 0
Bit 0.7 = 128: safety loop
Bit 1.0 = 1: safety valve
Bit 1.1 = 2: ignition
Bit 1.2 = 4: fuel valve 1
Bit 1.3 = 8: fuel valve 2
Bit 1.4 = 16: fuel valve 3 / pilot valve
Bit 1.5 = 32: reset
2 Std_u8 Read only 0 255 1 0 Info / Service
948 Contact feedback network counter register 14 Std_u8 Read only 0 255 1 0 SO
950 Required relay state (bit-coded)
Bit 0 = 1: Alarm
Bit 1 = 2: Safety valve
Bit 2 = 4: Ignition
Bit 3 = 8: Fuel valve 1
1 Std_u8 Read only 0 255 1 0 Info / Service
