LMV Series
Technical Instructions
LV5-1000
Menu Path Parameter Default Range Description
51.1
52.2
52.4
LEGEND - Password Access: (U)=User, (S)=Service, (O)=OEM, Shaded = Commonly Used, ** = Must Set, X = Has Function, / = Partial Function
LMV
OperationTempGas(Oil) (S)
Displays the recorded flue gas recirculation temperatures for each point. This is recorded
when commissioning the ratio control curves.
x
FGR MinPos (S) 0 deg 0-90 deg
Minimum angular position for the Aux 3 actuator when in temp.contr or TCautoDeact
operating modes. Serves as a default position if an auto deact occurs
.
x
FGR MaxPos Fact (S) 10% 0-100%
Maximum value (limit on the Aux 3 actuator) calculated by comparing the current FGR
temperature to the stored values.
x
LC_OptgMode (U) IntLC
ExtLC X5-03
IntLC
IntLC Bus
IntLC X62
ExtLC X62
ExtLC Bus
Current operating mode of the LMV5. Can also be changed at: Params & Display >
LoadController > Configuration > LC_OptgMode . If "Load Controller not active..." message
was seen under: Params & Display > LoadController > Configuration > LC_OptgMode , adjust
this parameter to "IntLC" and return to Params & Display > LoadController > Configuration >
LC_OptgMode .
x x x
Ext Inp X62 U/I (S) 4..20 mA
4..20 mA
2..10 V
0..10 V
0..20 mA
See: Params & Display > LoadController > Configuration > Ext Inp X62 U/I
x x x
TL_Thresh_Off (S) 203 F 32-3632 F See: Params & Display > LoadController > TempLimiter > TL_ThreshOff
x x x
TL_SD_On (S) -5% -50-0% See: Params & Display > LoadController > TempLimiter > TL_SD_On
x x x
Sens
or Select (S) Pt100
Pt100
Pt1000
Ni1000
TempSensor
PressSensor
Pt100Pt1000
Pt100Ni1000
NoSensor
See: Params & Display > LoadController > Configuration > Sensor Select
x x x
MeasureRangePtNi (S) 302 F
302 F
752 F
1562 F
See: Params & Display > LoadController > Configuration > MeasureRangePtNi
x x x
Params & Display>
SystemConfig
Read Only
Params & Display>
SystemConfig>
TempLimiter
Params & Display>
Flue Gas Recirc.
SCC Inc. Page 43 Section 3
