Siemens LMV5 Series Technical Instructions

TechnicalInstructions  LMVSeries
DocumentNo.LV5‐1000
Section7 Page22 SCCInc.

AZLSays“FanSpeedNotReached”or“ControlRangeLimitationVSDModule”

Duringburneroperation,theLMV52sendsa0/4‐20mAsign al totheVSDtocontrolthespeed
oftheblower.ThespeedsensorsendsfeedbacktotheLMV52toletitknowtheactualspeed
oftheblower.Ifthespeedistoohighortoolow,theLMV52willincreaseordecreasethe
signaltotheVSDaccordingly.However,therearelimitsonhowmuchtheLMV52canincrease
ordecreasethesignal.Iftheselimitsaremet,theLMV52willlockoutwithoneofthefollowing
messages:

 “FanSpeedNotReached”–Errorcode15,diagnostic10or40
 “ControlRangeLimitationVSDModule”–ErrorcodeA9,diagnostic0D

“FanSpeedNotReached”indicatesthattheblowerspeedisstilltooloweventhoughthe
LMV52hasincreasedthe0/4‐20mAsignalasfaraspossible.

“ControlRangeLimitationVSDModule”indicatesthattheblowerspeedistoohigheventhough
theLMV52hasdecreasedthe0/4‐20mAsignalasfaraspossible.

Ifeitherofthesemessagesappears,dothefollowing:

1. IncreasetheramptimesofboththeVSDandLMV52.ShorterramptimesontheVSDand
LMV52createamoredemandingapplicationfortheVSD.Simplyput,ashorterramptime
willcausetheVSDtodraworabsorbmuchmoreamperageforagivenchangeinblower
speedsincethechangeinspeedoccursmorequickly.Toadjusttheramptimesofthe
LMV52,usethefollowingmenupaths:

Params&Display>RatioControl>Times>OperatRampMod
Params&Display>RatioControl>Times>TimeNoFlame

2. Largeblowermotorsconnectedtolarge,heavyblowerwheelshavehighrotatinginertia.
Astheinertiaoftheblowerwheelincreases,thepowerneededtoaccelerateand
deceleratetheblowerincreases.Ifincreasingtheramptimes
doesnothelp,abraking
resistormayneedtobeinstalledontheVSDtohelpdecreasethespeedoftheblower
motormorequickly.









