LMV Series
Technical Instructions
LV5-1000
Menu Path Parameter Default Range Description
51.1
52.2
52.4
LEGEND - Password Access: (U)=User, (S)=Service, (O)=OEM, Shaded = Commonly Used, ** = Must Set, X = Has Function, / = Partial Function
LMV
var. RangePtNi (S) 1562 F 32-1562 F
is set to 1562F, this scales the high end of INPUT X62 for remote
x x x
Ext Inp X61 U/I (S) 0..10 V
2..10 V
0..10 V
Configuration of terminal X61. Can be 0-10VDC, 2-10VDC, 0-20mA or 4-20mA.
NOTE : For 4-20mA signals, signal limits are 3mA to 21mA. For 0-10 VDC signals, signal limit is
10.5 VDC. Signals not in this range will cause an alarm.
x x x
MRange TempSens (S) 194 F 32-3632 F
Sets the end of the scale for a temperature transducer connected to terminal X61. Also, this
serves to scale INPUT X62 if used for remote temperature setpoints.
x x x
MRange PressSens (S) 29 PSI 0-1449 PSI
Sets the end of the scale for a pressure sensor connected to terminal X61. Also, this serves to
scale INPUT X62 if used for remote pressure setpoints.
x x x
Ext Inp X62 U/I (S) 4..20 mA
4..20 mA
2..10 V
0..10 V
0..20 mA
Configuration of terminal X62. Can be 0-10VDC, 2-10VDC, 0-20mA or 4-20mA. This terminal is
usually used for remote setpoint or remote modulation. This input signal is scaled by
parameter MeasureRangePtNi , MRange TempSens or MRange PressSens .
NOTE : For 4-20mA signals, signal limits are 3mA to 21mA. For 0-10 VDC signals, signal limit is
10.5 VDC. Signals not in this range will cause an alarm.
x x x
Ext MinSetpoint (S) 0% 0-100%
Establishes the minimum external setpoint that can be input via terminals X62 or via
Modbus. This is a percentage of the range of the attached sensor.
x x x
Ext MaxSetpoint (S) 60% 0-100%
Establishes the maximum external setpoint that can be input via terminals X62 or via
Modbus. This is a percentage of the range of the attached sensor.
x x x
Params & Display>
LoadController>
Configuration>
Analog Output
OutValuSelection (S) Load
See
Description
This selects the process v
alue associated with analog OUTPUT X63. The selected process
value will be transmitted from X63 with either a 0-20mA or a 4-20mA signal. The 15 choices
for this output are:
1) Load - The current load of the burner using 4-20mA.
2) Load 0 - The current load of the burner using 4-20mA or 0-20mA.
3) O2 - The percent O2 currently read by the stack O2 sensor.
4) Pos Air - The current position of the air actuator in angular degrees.
5) Pos Fuel - The current position of the fuel actuator in angular degrees.
6) Pos Aux1 - The current position of the Aux 1 actuator in angular degrees.
7) Pos Aux2 - The current position of the Aux 2 actuator in angular degrees.
8) Pos Aux3 - The current position of the Aux 3 actuator in angular degrees.
9) Speed VSD - The current speed of the VSD motor in percent.
10) Flame - The current raw flame signal.
11) Temp Pt1000 - The temperature read by the Pt1000 sensor on terminal X60.
12) Temp Ni1000 - The temperature read by the Ni1000 sensor on terminal X60.
13) Temp Pt100 - The temperature read by the Pt100 sensor on terminal X60.
14) Temp X61 - The temperature read by the temperature transducer on terminal X61.
15) Press X61 - The pressure read by the pressure transducer on terminal X61.
x x x
Params & Display>
LoadController>
Configuration
SCC Inc. Page 34 Section 3
To Next Page
