LMV Series Technical Instructions
LV5-1000
SCC Inc. Page 2 Section 3
3-2: Parameter List
A
D
G
L - cont
O
Absolute Speed 39, 40 Date 5, 45 GasFiring 6, 44 LossFlameTest 46 O2 Alarm 22
actTmpFGR-sensor 42 DateFormat 36 GasPressureMax 13 LossOfFlame 16 O2 Content Air 27
Actuator Addressing 37 DelayLackGas 9 GasPressureMin 13 LowfireAdaptPtNo ** 24 O2 Control 22
Actuator/VSD Activation 20 DelayStartPrev 9 GasStartCount 6, 44 M
O2 CtrlThreshold 24
AdaptionLoad 35 DelaytimeFGR Gas(Oil)
42 Gateway status 6 MainsFrequency 11 O2 MaxValue 22
AdditionalSens 32 DeleteCurves 37 GatewayBASoff 6 ManVar O2 Ctrl 28 O2 Sensor 40
Address 36 Diag Reg State 28 GatewayBASon 6 Max Dyn Dev 40 O2 Setpoint 6, 41
Adjust. Temp O2 26 Direction of rotation 37 H
Max Stat Dev 40 O2Ctrl activate 7
AfterburnTme 9 Display Contrast 37 HeavyOil 16 MaxLoadGas(Oil) 19 O2Ctrl/LimitrGas 44
AirPressureTest 12 D-Part 29 HeavyOilDirStart 14 MaxSafetyTGas 8 O2Ctrl/LimitrOil 44
Air-related Load 28 DriveLowfire Gas 11 HomePos 17 MaxSafetyTOil 8 O2InitOffset 26
AirTempX60PT1000 41, 44 DriveLowfire Oil 11 I
MaxTempFlGasGas 41 O2MaxManVariable 25
Alarm act/deact 5 E
I High-Fire 23 MaxTempFlGasOil 41 O2MinManVariable 25
AlarmDelay 9 Ext Inp X61 U/I 34 I Low-Fire 23 MaxTmeLowFire 9 O2ModOffset 24
AlarmStartPrev 10 Ext Inp X62 U/I 34, 43 IgnitionPos ** 18 MaxTmeMod 32 O2SensServTim 40
Allowed Pot.diff 44 Ext MaxSetpoint 34 IgnOilPumpStart 10 MaxTmeStage 32 O2SensServTimRes 40
Autom/Manual/Off 7, 21 Ext MinSetpoint 34 InputController 13 MaxTmeStartRel 10 O2TrimBehavior 24
B
ExtranLightTest 14 InterfacePC 6 MeasureRangePtNi 33, 43 OEM Password 45
Baudrate 36 F
Interval1Gas 8 MinActuatorStep 30 OilPressureMax 13
BurnerID ** 6, 45 Factor FGR Gas(Oil) 42 Interval1Oil 8 MinLoadGas(Oil) 19 OilPressureMin 13
C
FanRunupTme 7 Interval2Gas 8 MinOnTmeOilPump 8 OilPumpCoupling 10
Calc PI again 23 FaultHistory 5 Interval2Oil 8 MinT_PrepurgeGas 7 OilStage1/Mod 6, 44
ColdStartOn 31 FGR MaxPos Fact 43 I-Part 29 MinT_PrepurgeOil 7 OilStage2 6, 44
CombEfficiency 28, 41 FGR MinPos 43 L
MinTmeHomeRun 9 OilStage3 6, 44
Config X5-03 13 FGR-Mode 42 Language 36 MinTmeStartRel 7 OilStartCount 6, 44
Config_PS-VP/CPI 12, 16 FGR-PS/FCC 12 LC Analog Output 44 MRange PressSens 34 Operation Mode 19
ContinuousPurge 11 FGR-sensor 42 LC_OptgMode 33, 43 MRange TempSens 34 OperationTempGas(Oil)
43
ContPilotGas 11 FlameSig ION 15 Load of Ignition 26 N
OperatRampMod 21
ContPilotOil 11 FlameSig QRI_B 15 Load_SW_from_PC
46 NormalOperation 5 OperatRampStage 21
Curr Flow Rate 6, 45 FlueGasTemp 6, 41 LoadCtrlSuspend 24 NormDirectStart 10 OptgMode 22
Current O2 Value 6, 41 FlueGasTempSens 41 LoadMaskHighLim 20 Num Dev >0.3% 40 OptgMode COx Gas 27, 44
CurrentFuel 5 ForcedIntermit 10 LoadMaskLowLimit
20 Num Dev >0.5% 40 OptgMode COx Oil 27, 44
CurrMode 0/4mA 35 FuelSelect 5 Local / Remote 36 Num Puls per R 39 OutValuSelection 34
CurveParams ** 19 FuelTrainGas ** 11 LockoutCounter 6 NumberTauSuspend 26
FuelTrainOil ** 11 LockoutHistory 5 NumFuelActuators 21
