LMV Series
Technical Instructions
LV5-1000
Menu Path Parameter Default Range Description
51.1
52.2
52.4
LEGEND - Password Access: (U)=User, (S)=Service, (O)=OEM, Shaded = Commonly Used, ** = Must Set, X = Has Function, / = Partial Function
LMV
ContinuousPurge (S) deact
activated
deactivated
off Sloop
deac/VSD-SL
Sets the operation of the blower.
1) activated - blower runs in all phases. Typically used to prevent return heat from coming
back into the burner.
2) deactivated - blower is called on and off as needed.
3) off Sloop - continuous purge is activated, but the fan will stop if the safety loop is opened.
4) deac/VSD-SL - continuous purge is deactvated and the VSD will be set to zero speed if the
safety loop is opened.
DriveLowfire Gas (O) Lowfire P54
DriveLowfire Oil (O) Lowfire P54
FuelTrainGas (O)** Not Set
DirectIgniG
Pilot Gp1
Pilot Gp2
Selects the fuel train for gas.
1) DirectIgniG - Direct spark ignition gas.
2) Pilot Gp1 - Pilot ignition for European gas burners
3) Pilot Gp2 - Pilot ignition for North American gas burners (See Section 5).
FuelTrainOil (O)** Not Set
LightOilLO
HeavyOilHO
LO w Gasp
HO w Gasp
Selects the fuel train for oil.
1) LightOilLO - Direct spark ignition for light oil.
2) HeavyOilHO - Direct spark ignition for heavy oil.
3) LO w Gasp - Gas pilot ignition for light oil.
4) HO w Gasp - Gas pilot ignition for heavy oil.
FuelTrainGas (O)
FuelTrainOil (O)
ContPilotGas (O) deact
ContPilotOil (O) deact
MainsFrequency (O) 60 Hz
50 Hz
60 Hz
Set to the freqency of the local AC power grid. For North America select 60 Hz.
x x x
x
Params & Display>
BurnerControl>
Configuration>
ConfigGeneral
LowfireP54
LowfireP50
Params & Display>
BurnerControl>
Configuration>
ConfigGeneral>
FuelTrainReset
Resets the fuel train to a value of "invalid" (means not set, undefined). This allows removal a
previously configured fuel train, if it is no longer being used. Resetting this will also remove
the fuel-air ratio curves for the fuel that is reset.
Params & Display>
BurnerControl>
Configuration>
ConfigGeneral
Activates or deactivates a continuous pilot. Each fuel can be configured separately. In this
case continuous pilot is defined as a pilot from the end of phase 42 (normal pilot light off) to
the end of phase 62 (low fire shut down).
Go into parameter then
press Enter to reset
activated
deactivated
x x
x x x
x x
Controls the action of the actuators when lighting the main burner flame.
1) LowFireP50 - the LMV5 will start driving to StartPointO
p (typically point 1 - low fire) at the
beginning of phase 50. This is typically used if a fuel rich light off is
needed.
2) LowFireP54 -the LMV5 will not start driving to StartPointOp until the beginning of phase
54.
SCC Inc. Page 11 Section 3
