LMV Series
Technical Instructions
LV5-1000
Menu Path Parameter Default Range Description
51.1
52.2
52.4
LEGEND - Password Access: (U)=User, (S)=Service, (O)=OEM, Shaded = Commonly Used, ** = Must Set, X = Has Function, / = Partial Function
LMV
Params & Display>
AZL
Display Contrast (U) Change with < > keys, store with the Enter key, or cancel with the Esc key.
x x x
ASN (U)
x x x
ProductionDate (U)
x x x
SerialNumber (U)
x x x
ParamSet Code (U)
x x x
ParamSet Vers (U)
x x x
Params & Display>
AZL
SW Version (U) Software version on the AZL.
x x x
1 AirActuator (S)
x x x
2 GasActuat(Oil) (S)
x
x x
3 OilActuator (S)
x x x
4 AuxActuator (S)
x x x
5 AuxActuator2 (S)
x x
6 AuxActuator3 (S)
x x
DeleteCurves (S)
This deletes the ratio control (fuel / air) curves and the ignition positions. Curves must be
deleted if the direction of rotation on any actuator is to be changed.
x x x
1 AirActuator (O)
x x x
2 GasActuat(Oil) (O)
x x x
3 OilActuator (O)
x x x
4 AuxActuator (O)
x x x
5 AuxActuator2 (O)
x x
6 AuxActuator3 (O)
x x
ASN (U)
x x x
ProductionDate (U)
x x x
SerialNumber (U)
x x x
ParamSet Code (U)
x x x
ParamSet Vers (U)
x x x
Information concerning the AZL.
Enables addressing of the actuators. Select one of the actuators and press Enter.
The AZL will then serve as a guide through the rest of the procedure.
This procedure involves pressing a red button (hold about 1s) on the selected actuator. The
actuators can be wired and addressed in any order. The green LED will be on when the
actuator is powered and not addressed, and it will blink after it has been addressed.
NOTE: Holding the red button on the actuator down for approx. 10 sec will clear the
addressing on that actuator.
Adjust as needed
Read Only
Read Only
1 blink = Air
2 blink = Gas(Oil)
3 blink = Oil
4 blink = Aux 1
5 blink = Aux 2
6 blink = Aux 3
Params & Display>
Actuators>
Addressing
Sets the direction of rotation for each actuator, regardless of which fuel is selected.
Looking at the actuator with the shaft pointed at eye:
standard - shaft rotates counterclockwise to open.
reversed - shaft rotates clockwise to open.
These descriptions are opposite if viewed from the cover end of the actuator (shaft pointing
away from eye).
Params & Display>
Actuators>
ProductID>
1 AirActuator
Information concerning the currently addressed air actuator.
Params & Display>
Actuators>
DirectionRot
Go into parameter then
press Enter to delete
standard
standard
reversed
Read Only
Params & Display>
AZL>
ProductID
SCC Inc. Page 37 Section 3
