LMV Series
Technical Instructions
LV5-1000
Menu Path Parameter Default Range Description
51.1
52.2
52.4
LEGEND - Password Access: (U)=User, (S)=Service, (O)=OEM, Shaded = Commonly Used, ** = Must Set, X = Has Function, / = Partial Function
LMV
O2Ctrl/LimitrGas (S)
O2Ctrl/LimitrOil (S)
LC Analog Output (S) Load
See
Description
See: Params & Display > LoadController > Configuration > Analog Output > OutValuSelection
x x x
allowed Pot.diff (S) 15 10-15
Sets the allowable difference between channels A and B of the actuator's potentiometer.
Units are tenths of a degree, so 10 = 1.0 degrees.
x x
x
OptgMode COx Gas (S) deact
x
OptgMode COx Oil (S) deact
x
AirTempX60PT1000 (O) deact
activated
deactivated
See: Params & Display > O2 Module> Configuration > AirTempX60PT1000
x x
GasFiring (U) Hours run firing gas. Can be adjusted here. See: Operation > HoursRun
x x x
OilStage1/Mod (U) Hours run on modulating or stage 1 oil. Can be adjusted here. See: Operation > HoursRun
x x x
OilStage2 (U) Hours run on stage 2 oil. Can be adjusted here. See: Operation > HoursRun
x x x
OilStage3 (U) Hours run on stage 3 oil. Can be adjusted here. See: Operation > HoursRun
x x x
TotalHoursReset (U) Hours run on all fuels. Can be adjusted here. See: Operation > HoursRun
x x x
TotalHours (U)
x x x
SystemOnPower (U)
x x x
GasFiring (U) Hours run firing gas. Can be reset here. See: Operation > HoursRun
x x x
OilStage1/Mod (U) Hours run on modulating or s
tage 1 oil. Can be reset here. See: Operation > HoursRun
x x x
OilStage2 (U) Hours run on stage 2 oil. Can be reset here. See: Operation > HoursRun
x x x
OilStage3 (U) Hours run on stage 3 oil. Can be reset here. See: Operation > HoursRun
x x x
TotalHoursReset (U) Hours run on all fuels. Can be reset here. See: Operation > HoursRun
x x x
GasStartCount (U) Number of starts for gas. Can be adjusted here. See: Operation > StartCounter
x x x
OilStartCount (U) Number of starts for oil. Can be adjusted here. See: Operation > StartCounter
x x x
TotalStartCountR (U) Total number of starts. Can be adjusted here. See: Operation > StartCounter
x x x
TotalStartCount (U) Total number of starts. Cannot be reset.
x x x
GasStartCount (U) Number of starts for gas. Can be reset here. See: Operation > StartCounter
x x x
OilStartCount (U) Number of starts for oil. Can be reset here. See: Operation > StartCounter
x x x
TotalStartCountR (U) Total number of starts. Can be reset here. See: Operation > StartCounter
x x x
x x
Params & Display>
HoursRun>
These values CANNOT be adjusted or reset. See: Oper
ation > HoursRun
Params & Display>
HoursRun>
Reset
Params & Display>
StartCounter
Read Only
0 0-999999 hr
deactivated
COx Control
COx Limiter
Future functionality. Does nothing at this time.
Reset Only
Reset Only
Params & Display>
SystemConfig
Read Only
See: Params & Display > O2Contr/Alarm > GasSettings > OptgModeman deact
See
Description
Read Only
Params & Display>
StartCounter>
Reset
0 0-999999 hr
SCC Inc. Page 44 Section 3
