Siemens LMV5 Series Technical Instructions

TechnicalInstructions  LMVSeries
DocumentNo.LV5‐1000
Section7 Page2 SCCInc.
7‐2:CommonProblems

CANbusFaultsIncluding“AZLnotonBus”and“SystemTest”

The majority of all LMV5 wiring errorsarerelatedtothe wiring of the CANbus network.The
CANbusnetworkincludesthefollowingcomponents:

 LMV5controller
 AGG5.210transformer(s)
 Onemainfuse(FU1)andtwo12VACfuses(FU2,FU3)
 AZLdisplay
 AGG5.643specialCANbuscable
 SQM45/48/91actuators
 PLL52O
2
module(ifequipped)

AnillustrationoftheCANbusnetworkwithasingletransformerisshownbelowinFigure7‐2.1.

 

Figure7‐2.1:IllustrationoftheLMV5CANbusNetwork

