LMVSeriesTechnicalInstructions 

DocumentNo.LV5‐1000

SCCInc. Page11 Section7



LMV5WillNotStart(StaysinPhase12)



1. EnsurethattheLMV5isinautomaticmodethroughthefollowingmenupath:



ManualOperation>Autom/Manual/Off=Automatic



2. The burner will not start if the safety loop is open.Verify that there is 120 VAC on both

terminalsX3‐03.1andX3‐04.1.



3. Verifythatthereis120VACatburnerswitchinputterminalX5‐03.1.



4. VerifythattheLMV5isnotinalarm.Ifso,correcttheissuecausingthealarmandresetthe

fault.



5. Verifythatignitionpositionsaredefinedforallactivatedactuators,includingtheVSD.This

canbedonethroughthefollowingmenupath:



Params&Display>RatioControl>Gas/OilSettings>SpecialPositions>IgnitionPos



6. Verifythattheactualvalueoftheboilerislessthantheswitchonthresholdoftheburner

(setpoint+SD_ModOn).


