Menu Path Parameter Default Range Description
51.1 52.2 52.4
LEGEND - Password Access: (U)=User, (S)=Service, (O)=OEM, Shaded = Commonly Used, ** = Must Set, X = Has Function, / = Partial Function
LMV
LMV5x -> AZL (S)
Transfers a parameter set from the LMV5x to the AZL5. Note that the working parameter set
is in the LMV5, not the AZL5. Burner ID in LMV5 will overwrite burner ID in the AZL5.
x x x
AZL -> LMV5x (S)
Transfers a parameter set from the AZL5 to the LMV5. The burner ID of the LMV5 must be
blank (new LMV5) or must match the burner ID of the parameter s
et in the AZL5. This
feature is useful for transferring parameter sets to identical burners. NOTE: When
transferring parameter sets from the AZL5 to the LMV5, do not stop the transfer until
"Backup Restore Finished Parameter BC : complete or BC : partial" is shown on the AZL
screen. This could take up to 5 minutes. Do not disturb the LMV5 while the backup restore is
in progress.
x x x
Updating Load_SW_from_PC (S)
Enables updating of the AZL5 operating software via the ACS450 software. A .bin file
supplies the new software for the AZL5.
x x x
Access w-out PW (U) Access without password. Also called user level.
x x x
Access Serv (U) 9876
3 to 8
characters
Access with service level password.
x x x
Access OEM (U) START
4 to 8
characters
Access with OEM level password.
x x x
Access SBT (U) - - Access level not used.
x x x
PW Logout PW Logout (S) Deactivates all passwords, thus reducing access to us
er level.
x x x
LossFlameTest (U)
Enables testing of the flame sensor input on the LMV5 by electronically interrupting the
flame signal.
x x x
SLT Test (U) deact
activated
deactivated
This enables the safety limit thermostat (SLT) test to check upper safety limits.
activated - The internal load controller's setpoint AND switch-off threshold will be ignored,
allowing a test of a separate high limit control or pressure relief valve.
deactivated - feature is disabled.
x x x
SLT-Testload Mod (U) 100% 0-100% This sets the load for the SLT test in modulating operation.
x x x
SLT-Testload Stg (U) S3 S1-S3 This sets the load for the SLT test in staged operation.
x x x
SafetyCheckFunct
Press Enter to log out
Go into parameter then
press Enter to start
Updating>
ParamBackup
Press Enter for access
Go into parameter then
press Enter to start
Go into parameter then
press Enter to start
Go into parameter then
press Enter to start
PW Login
SCC Inc. Page 46 Section 3
HOME
HOME
P - LIST
