TechnicalInstructions  LMVSeries
DocumentNo.LV5‐1000
Section4 Page30 SCCInc.

SpecialFeaturesandSettings

The LMV5 has special features and settings that are very useful in some situations. Some of these
featuresaredetailedbelow.

Alarmact/deact Aninternalalarmsilence.AlarmsilencewillresetwhentheLMV5alarmisreset.

MinTmeStartRel PermitstheLMV5toholdinphase21foraspecifiedperiodoftimewiththestart
signalterminalenergized.Thiscanbeusedasadelaytoletstackand/orfreshair
dampersopen.

PressReacTme Allows the LMV5 to disregard the high and low gas / oil pressure switches for a
settable time period after the main gas / oil
 valves open.This is used with
automaticresetpressureswitchessothatpressurespikes duetothemainvalves
opening will be ignored.This also allows  for a reduced delta between switch
setpoints and normaloperatingpressures.Thistimecanalsobe
 reduced to0.2
seconds,deactivatingthefeature.Notusedwithmanualresetswitches.

NormDirectStart Permits the LMV5 to go from post‐purge directly into pre‐purge without turning
thebloweroff.Theblowe r airpressureswitchmustbecheckedbyusinga3‐way
solenoidvalve.Thesolenoidvalveisconfiguredun
derparameterStartSignal.

ForcedIntermit Shutstheburnerdownonceevery24hourstocycleandcheckflamescanner,air
pressureswitch,POC,andothersafetydevices.

DriveLowFire Startsdrivingtolowfire(StartPointOp)immediatelyaftermainfuelvalvesopen.
Enableslessairtobepu
tonthepilotforignition,andenablesafuelrichlightoff
withoutcreatingexcessiveCO.Alsocalled"GoldenStart"functionality.

StartReleaseGas ConfiguresterminalX7‐03.2asastartreleaseforgas,CPIgas,CPIoil,orCPIgas+
oil.GasandoilPOCscanbewiredhere,freeingupterminalX9‐03.2forgasvalve
proving.CPIstandsfor
ClosedPositionIndication,whichisessentiallythesameas
ProofofClosure(POC).

Config_PS‐VP/CPI Configures terminal X9‐03.2 for PS‐VP (Pressure Switch‐Valve Proving), CPI gas,
CPI oil, or CPI gas + oil.CPI stands for Closed Position Indication, which is
essentiallythesameasProofofClosur
e(POC).

ConfigX5‐03 Terminal X5‐03.3 can be configured to hold the LMV5 in phase 36 (ignition
position).TerminalX5‐03.2canbeconfiguredtodisableO
2
trim.

HeavyOilDirStart TerminalX6‐01.3canbeusedasaninputforanexternalflamerelay.

ReacTmeLossFlame Adjustableflamefailureresponsetime(FFRT).


