LMVSeriesTechnicalInstructions 

DocumentNo.LV5‐1000

SCCInc. Page7 Section7



FaultPositioningActuator–ErrorCode15(continued)



6. Ifeverythingelsechecksoutokay,replacetheactuator.



InternalFaultActuator–ErrorCode19



SQM45andSQM48actuatorshavedualpotentiometersthatprovidefeedbacktotheLMV5to

verifyactuatorposition.Whenthesetwopotentiometersdisagree,theLMV5faultswithan

errorcode19.Thediagnosticcodewilldetailwhichactuatorishavingtheproblem.Ifanerror

code19isencountered,checkthefollowing:



1. EnsurethatparameterallowedPot.diffissetto15.Thisallowsamaximumdisagreement

of1.5°betweenthetwopotentiometers.



2. IfallowedPot.diffissetto15andtheLMV5continuestoreceiveerrorcode19,the

actuatormustbereplaced.Thelikelycauseofthedamagedactuatorisexcessivesideload

ontheactuatorshaftorexcessivevibration.Overtime,excessivesideloadontheactuator

shaftcanweardowntheshaftbearingsoftheac

tuator.Sincethepotentiometersare

mounteddirectlyontothebackoftheshaft,theywilldisagreemoreandmoreastheshaft

bearingswear.Excessivevibrationcanalsocausepotentiometerwearandleadtoanerror

code19.



3. Itisimperativethatpropercouplingsareusedwhenmountingactuators.Itishighly

recommendedtouseanSCCflexiblecouplingonallactuators.SCCcouplingseliminate

excessivesideloadduetotheirdesign.Furthermore,SCCcouplingsallowupto1/16”of

parallelmisalignmentand3°ofangularmisalignmentbetweentheactuatorandvalve

shafts.SeeDocumentNo.CPBK‐1000formoreinformationonavailableflexiblecouplings.



4. Itisalsoimportanttousearigidmountingbracketwhenmountinganyactuator.Excessive

vibrationovertimecanwearthepotentiometertracks.Ifthewearistoosevere,errorcode

19canresult.Rigidmountingbracketshelptominimizetheeffectsofvibration.SCCoffers

awidevarietyofbracketsandfullyassembledvalveactuatorassembliestoensureproper

mountingofactuators.SeeSection1formoredetails.


