LMVSeriesTechnicalInstructions 

DocumentNo.LV5‐1000

SCCInc. Page21 Section7



UnsuccessfulVSDStandardization(continued)



6. Monitorthespeedoftheblowermotorduringthestandardizationprocess.After

standardizationisactivated,therealtimespeedcanbereadusingthefollowingmenupath:



Params&Display>VSDModule>Speed>AbsoluteSpeed



 Duringstandardization,theabsolute speedshouldriseuptoapeakvalueandholdsteady

atthatvalueforafewseconds.Then,thevalueshoulddropbackdowntozero(ornear

zero).



 Thepeakvaluethatisseenshouldberecordedasthestandardizedspeed.Ifthisdoesn’t

happen,it’slikelythatthere’saproblemwiththeVSDorthespeedsensor.


