Siemens LMV5 Series Technical Instructions

TechnicalInstructions  LMVSeries
DocumentNo.LV5‐1000
Section6 Page8 SCCInc.


NOTE:Bothsensorsarerequiredtodoaboilerefficiencycalculation.Theboilerefficiency
calculationisnotrequiredforO
2
trimoperation.Ifsensorsareactivatedbutnotreadingcorrectly
ornotwiredcorrectly,theO
2
trimwillnotactivate.Burnerinlettemperaturemustbereadto
performatemperature‐compensatedstartupontheLMV52.440.

4. Settheappropriateactuatorsto“airinfluen”(airinfluenced).Thesearetypicallyonlytheactuators
/VSDthatwilldirectlyinfluencetheburnerairrate.Themenupathfortheseparametersis:

 Params&Display>RatioControl>GasSettings

Typically,onlytheairactuatorandtheVSD(ifused)aresettoairinfluenced.Ifused,theFGR
actuatorisusuallynotsettoair
influenced.

5. SettheoperatingmodeoftheO
2
systemto“mandeact”(manuallydeactivated).Thisisnecessary
fortheO
2
systemcurvestobecommissioned.Themenupathforthisparameteris:

Params&Display>O2Contr/Alarm>GasSettings>OptgMode=mandeact

6. Setthecurvepointatwhichthelowfiredelaytimewillbemeasured.ThisistypicallysettoPoint2,
unlessoversizedexhauststackswithhighturndownburnersareencountered,whichmay
makegas
velocityinthestacktoolowatlowfire.Fortheseapplications,settingthisparametertoahigher
pointthanPoint2willincreasethegasvelocitypasttheO
2
sensorandyieldamoreresponsiveO
2

reading.Thiscanbesetthroughthefollowingmenupath:

Params&Display>O2Contr/Alarm>GasSettings>ControlParam>LowfireAdaptPtNo

7. SettheloadvalueatwhichtheO
2
trimwilldisengage.Typi cally,thisissettotheloadvaluefor
Point2ontheFuel‐AirRatioControlCurve.TheexceptiontothisisifparameterLowfireAdaptPtNo
issettoapointotherthanPoint2.Ifthisis thecase,setthisfortheloadvaluethatcorrespondsto
thepointsetbyLowfireAdaptPtNo.Thiscanbesetthroughthefollowingmenupath:

Params&Display>O2Contr/Alarm>GasSettings>ControlParam>O2CtrlThreshold

8. Setthedesir
edtypeofpre‐control.FormostnaturalgasburnerswherethegapbetweenO
2
curves
islargeenoughthattheLambdaFactorcanbelearned(seeO
2
ControlandO
2
AlarmCurvesinFigure
6‐2),thisshouldbesetto"likePair".The"liketheory"settingistypicallyusedforoilburner s,and
"LambdaFact1"shouldonlybeusedasalastresort.Themenupathforsettingthetypeofpre‐
controlis:

Params&Display>O2Contr/Alarm>GasSettings>ControlParam>TypeAirChange







