Siemens LMV5 Series Technical Instructions

TechnicalInstructions  LMVSeries
DocumentNo.LV5‐1000
Section6 Page34SCCInc.


 Ifacombustionairtemperaturesensorisinstalledandactivated,theairtemperaturewillbe
recordedwhenthelastpointisenteredintotheO
2
ControlCurve.Thistemperatureisstoredunder
thefollowingmenupath:

Params&Display>O2Contr/Alarm>Gas/OilSettings>Startmode>Adjust.TempO2

Thisisthetemperaturethatwillbecomparedagainstthecurrentairtemperaturetoperform
temperaturecompensatedlight‐offifparameterStartModeissetto“IgnLoadTC”or“IgnPtWithTC”
(LMV52.440only).

 WhenterminalX5‐03.2isproperly configured(seeSection3‐Parameters),itcanbeenergizedto
causeadeactivationoftheO
2
trim.Whenthisisdone,theLMV52willoperateontheO
2
Ratio
ControlCurve.TheO
2
richandleanlimitswillbeactiveaslongasthereisavalidO
2
signal.This
deactivationviaX5‐03.2occurswithoutanotificationbeingdisplayedontheAZL52.

 Pre‐purgemustbesetsothat20.9%(+/‐2.0%O
2
)isreadbytheQGO20sensor.Ifthisisnotmet,a
lockoutordeactivationwilloccurdependingonthesettingofparameterOptgMode.

 WhenusingtheLMV52.440onloworultra‐lowNOxmeshburners,aStartModeof“IgnPtWithTC”is
typicallyusedcombinedwithadjustingO2InitOffsetinthenegativedirection(morerich).Ifdone
properly,thisshouldmakethetransitionfromlight‐offpositiontolowfirericherthannormal
operationsothatthetransitionisstableandreliableundervaryingenvironmentalconditions.
While
theburnerisbeingheldatPoint2awaitingNumberTauSuspendtoexpire,theO2InitOffsetwill
graduallydissolveandthe%O
2
willbetrimmedtosetpointbeforetheburnerisreleasedto
modulate.

 TheAGOgascollectorshouldbemountedpertherequirementsshownbelow:


