Device Display Meaning for the LMV5x System Corrective Action
B6 Time block too long: Time block 0
B7 Time block too long: Time block 1
B8 Time block too long: Time block 2
B9 Time block too long: Time block 3
BA Time block too long: Time block 4
BB Time block too long: Time block 5
BC Time block too long: Time block 6
BD Time block too long: Time block 7
C0 CRC fault in page
E0 Identpower
E1 Controller parameter KP
E2 Scanning time
EA Invalid branch in EEPROM module()
EB Invalid branch in EEPROM module()
EC Invalid branch in EEPROM module()
ED Invalid branch in EEPROM module()
EE Invalid branch in EEPROM module()
EF Invalid branch in EEPROM module()
F0 Fault during ROM test
F1 Fault during RAM test
F2 Fault during RAM test, register bank 0
F3 Fault during RAM test, IDATA range
F4 Fault during RAM test, XDATA range
F5 Stack pointer does not point at stack
F6 Stack overflow
FE Fault messages in fault management
FF Fault messages in fault management
Fault with Base Unit (LMV5) Internal Load Controller
A6
LMV5
Load
Module
Internal Fault
Load Controller
If fault occurs sporadically, reduce electrical noise.
If fault occurs continuously, replace LMV5.
Section 7 Page 48 SCC Inc.
