5.4 Example 2: Assigning the Variable Type, Limits, Attributes, Short Text
Position properties
Example 2
The following example defines a variable for which the properties variable type, limits, input
mode, alignment and position are set.
DEF Var2 = (I/0,10///wr1,al1///,,300)
Variable type: INTEGER
Limits or toggle field entries: MIN: 0
MAX: 10
Attributes:
Input mode: Read-only
Alignment of short text: Right-justified
Position of short text:
Width: 300
See also
Variable parameters (Page 92)
Variables
5.4 Example 2: Assigning the Variable Type, Limits, Attributes, Short Text Position properties
SINUMERIK Integrate Run MyScreens (BE2)
Programming Manual, 12/2017, 6FC5397-1DP40-6BA1 85
