Examples for cycle masks
10
10.1 Examples for cycle masks
When installing SINUMERIK Operate, examples for cycle masks created with Run MyScreens
are also saved to the system.
The Run MyScreens examples are available under the following archive paths:
[System Siemens directory]
...\siemens\sinumerik\hmi\template\easyscreen\
...
standard\ Help screens, PNG
x3d\ Help screens / animations
...
Milling\ Fräsbearbeitung
Turning\ Drehbearbeitung
...
deu\ German description
eng\ English description
Examples in the commissioning operating area can be found on the HMI user interface:
Horizontal softkey system data → HMI data → Templates → Examples → Easy Screen → …
(see above).
Brief description of the examples
● Milling
– Drilling example: This is where a position can be added
– Measure workpiece example: This is where a cycle call can be generated and processed
via NC start while the dialog is open
– Workpiece counter example: This shows how GUDs should be handled
● Turning
– Fixtures: this contains a tailstock, bar loader, part catcher
– Measure workpiece example: This is where a cycle call can be generated and processed
via NC start while the dialog is open
– Drilling example: This is where a position can be added
SINUMERIK Integrate Run MyScreens (BE2)
Programming Manual, 12/2017, 6FC5397-1DP40-6BA1 287
