5.25
Variable S_LANG
Description
The current language can be queried in the configuration with the screen property S_LANG.
Programming
Syntax:
S_LANG
Description:
Query of the current language
Return value:
Language code from resources.xml, e.g. "deu", "eng", etc.
Example
REG[0] = S_LANG
See also
LANGUAGE (Page 130)
Variables
5.25 Variable S_LANG
SINUMERIK Integrate Run MyScreens (BE2)
118
Programming Manual, 12/2017, 6FC5397-1DP40-6BA1
1103
1105
