5.23
S_CHAN variable
Description
The S_CHAN
variable determines
the number of
the current
channel for
display or
evaluation
purposes.
Programming
Syntax:
S_CHAN
Description:
Query of the current channel number
Return value:
Channel number
Example
REG[0] = S_CHAN
See also
CHANNEL (Page 128)
Variables
5.23 S_CHAN variable
SINUMERIK Integrate Run MyScreens (BE2)
116
Programming Manual, 12/2017, 6FC5397-1DP40-6BA1
1101
1103
