Variable S_CONTROL
Description
The current control name can be queried in the configuration with the screen property
S_CONTROL.
Programming
Syntax:
S_CONTROL
Description:
Query of the current control name
Return value:
The control name is the section name in the mmc.ini
Example
REG[0] = S_CONTROL
See also
CONTROL (Page 129)
Variables
5.24 Variable S_CONTROL
SINUMERIK Integrate Run MyScreens (BE2)
Programming Manual, 12/2017, 6FC5397-1DP40-6BA1
117
1102
1104
