Backing up and restoring data
4.12 Operating a service PC/PC in the network
PCU-Basesoftware (IM8)
Commissioning Manual, 02/2014, 6FC5397-1DP40-4BA0
111
Configure the network settings of the PG/PC
Once you have connected a PG/PC in the network, make the network settings on the
PG/PC.
The basic procedure for setup under Windows 7 or Windows XP is described below.
Detailed information from Microsoft is provided in Windows under "Help and Support" or in
the Internet: Microsoft Windows support (http://windows.microsoft.com/en-
US/windows/windows-help#windows=windows-7)
● The PG/PC is networked with the PCU in one of the following ways:
– The PG/PC is connected to the PCU with an Ethernet cable (either directly or via a
switch)
See: Connection options in the system network (Page 107)
– The PG/PC is networked with the PCU via an interface on the NCU and the routing is
configured.
See: Configuring routing in the network (Page 109)
● A current Microsoft Windows operating system is installed on the PG/PC
● The PG/PC is switched on
