There are two variants of cylinder surface transformation, i.e.
1. with groove side offset (ON)
2. without groove side offset (OFF)
:LWKRXWJURRYHVLGHRIIVHW
/RQJLWXGLQDOJURRYHZLWKSDUDOOHOOLPLWDWLRQ
:LWKJURRYHVLGHRIIVHW
7UDQVYHUVHJURRYH/RQJLWXGLQDOJURRYH
Figure 21-1 Grooves with and without groove side offset
21.4.5 Example: Milling machine with the XYZ-AC axis configuration
Example: Milling machine with the XYZ-AC axis configuration
Example of an axis configuration on the following machine:
Technologies and cycles
21.4 Milling
SINUMERIK Operate (IM9)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 523
