Note
This function automatically refreshes the display.
CursorX – cursor X position
Syntax: ReturnValue = ReadCWProperty (GraphVarName, " CursorX ")
WriteCWProperty (GraphVarName, " CursorX ", Value)
Description: X position of the cursor.
Parameters: GraphVarName Name of the display variable which contains a SlEs‐
GraphCustomWidget
Return Value Read value of the property (double)
Value Value to be set (double).
Note
This function automatically refreshes the display.
CursorY – cursor Y position
Syntax: ReturnValue = ReadCWProperty (GraphVarName, " CursorY ")
WriteCWProperty (GraphVarName, " CursorY ", Value)
Description: Y position of the cursor.
Parameters: GraphVarName Name of the display variable which contains a SlEs‐
GraphCustomWidget
Return Value Read value of the property (double)
Value Value to be set (double).
Note
This function automatically refreshes the display.
CursorY2 - cursor Y position referred to the second Y axis (right)
Syntax: ReturnValue = ReadCWProperty (GraphVarName, " CursorY2 ")
WriteCWProperty (GraphVarName, " CursorY2 ", Value)
Description: Y position of the cursor referred to the second Y axis (right).
Parameters: GraphVarName Name of the display variable which contains a SlEs‐
GraphCustomWidget
Return Value Read value of the property (double)
Value Value to be set (double).
Graphic and logic elements
7.5 SIEsGraphCustomWidget
SINUMERIK Integrate Run MyScreens (BE2)
Programming Manual, 12/2017, 6FC5397-1DP40-6BA1 229
