Bit 1 = 1 Block search with calculation, with approach
Notice:
In a ShopMill/ShopTurn program, the search is performed only on G code-blocks.
Bit 3 = 1 Skip EXTCALL programs
Bit 5 = 1 Block search with test run
MD52212 $MCS_FUNCTION_MASK_TECH General function screen for all technolo‐
gies
Bit 3 Block search cycle for ShopMill / ShopTurn
= 0 The E__ASUB or F_S_ASUB cycles are not called in the block search cycle
PROG_EVENT.SPF
= 1 The E__ASUB (under ShopMill) or F_S_ASUB (under ShopTurn) cycles are called in the
block search cycle PROG_EVENT.SPF
Bit 5 Call block search function for SERUPRO
= 0 CYCLE207 is not called in the block search cycle PROG_EVENT.SPF.
= 1 In the block search cycle PROG_EVENT.SPF (for block search cycle with program test
- SERUPRO), the cycle for SERUPRO (CYCLE207) is called. After block search with
program test (SERUPRO), cycle CYCLE207 triggers the output of the collected machine
commands.
Bit 15 Do not set $MC_TOOL_CARRIER_RESET_VALUE after block search
= 0 In the block search cycle Prog_Event.SPF, the current tool holder is written into the ma‐
chine data $MC_TOOL_CARRIER_RESET_VALUE.
= 1 In the block search cycle Prog_Event.SPF, the current tool holder is not written into the
machine data $MC_TOOL_CARRIER_RESET_VALUE.
Bit 16 Do not automatically execute swivel plane after block search
= 0 In the block search cycle PROG_EVENT.SPF, the section for standard cycles: Swivel
plane is executed
= 1 In the block search cycle PROG_EVENT.SPF, the section for standard cycles: Swivel
plane is not executed
Bit 17 Do not automatically align turning tool after block search
= 0 In the block search cycle PROG_EVENT.SPF, the section for aligning the turning tool is
executed.
= 1 In the block search cycle PROG_EVENT.SPF, the section for aligning the turning tool is
not executed.
Note
The "Block search mode" softkey is only displayed, if, in the machine data MD51024 or
MD51028, more than one version for the block search has been defined; for example "Block
search with calculation without approach" and "Block search with calculation with approach".
When so doing, take into account that the search versions set active in the "Block search
mode" window are also referred to the program.
Customizing the "Machine" operating area
8.8 Block search
SINUMERIK Operate (IM9)
126 Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1
