The meaning of the settings are as follows:
Table 4-3 Settings in the configuration file tcu.ini
Settings Meaning
SYSTEM The resolution is not specially set during run-up. i.e. the resolution last used
in the system is active, e.g. the resolution which had been set manually in
the Control Panel.
AUTO_OP_1 Default setting:
During run-up, the resolution is automatically set ("PCU panel" has priority)
in accordance with the following scenarios:
Example 1: There is a PCU panel (irrespective of whether there is a PCU monitor and
TCU panels):
[In active TCU mode:
The following additional condition applies: PCU is activated (with dynamic
resolution switching enabled)]:
The resolution is set to the max. resolution of the PCU panel
(max. 1920x1080).
Example 2: There is no PCU panel, however there is a PCU monitor (irrespective of
whether there are any TCU panels):
[In active TCU mode:
The following additional condition applies: PCU is activated (with dynamic
resolution switching enabled)]:
The resolution is not specially set; i.e. the resolution last used in the system
is active, e.g. the resolution which had been set manually in the Control Panel.
(Different to AUTO_OP_2 !)
AUTO_OP_2 Like AUTO_OP_1, except:
Example 2: There is no PCU panel, however there is a PCU monitor (irre‐
spective of whether there are any TCU panels):
[In active TCU mode:
The following additional condition applies: PCU is activated (with dynamic
resolution switching enabled)]:
The resolution is set to the max. resolution of the PCU monitor, reduced to
the next lowest SINUMERIK resolution. The SINUMERIK resolutions are
640x480, 800x600, 1024x768, 1280x1024, 800x480, 1280x800, 1366x768
and 1920x1080.
Example: In the case of a PCU monitor with a max. resolution of 2048x1152,
the SINUMERIK resolution setting is 1920x1080.
AUTO_MON_1 During run-up, the resolution is automatically set ("PCU monitor" has priority)
in accordance with the following scenarios:
Configuration of the system
4.10 Set the resolution in the tcu.ini
PCU Base Software (IM10)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 39
