Table 6-4 Settings in the "Connect a Share" dialog box in the Service Center
Section Settings Purpose
Connection Local drive Select drive letters under which the network directories are to be accessible on the PC system.
The drive letters Z, Y and X are assigned to USB interfaces on SINUMERIK TCUs and operator panels. Do
not use these drive letters for other purposes in order to avoid problems when using these USB interfaces.
Remote path Specify the device in the network and share name of the resource.
Syntax: \\Name of the server\share name of the network directory
Example: \\Backup_Server\PCU_Backup
Credentials User name Enter the user account under which the resource in the network can be accessed.
If you have shared the resource on the server for certain users only, you must enter one of these user accounts
here.
Password Enter the password of the user account.
Further information
You will find information about releasing directories in the network and network drives in the
following chapters:
● Release directory of the PC/PC in the network (Page 148)
● Creating a shortcut to the network drive (Page 151)
Backing up and restoring data
6.9 Network settings in the Service Center
PCU Base Software (IM10)
138 Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1
