Entries Meaning
MagazineMoveMessage True - "Magazine movement running" or "Magazine move‐
ment ended" message is displayed.
False - default setting, message is not displayed.
ToolLoadErrorMessage Refers to the output of the fault message due to a negative
PLC.
True - default setting, the fault message is displayed.
False - the fault message is not displayed.
The following settings refer to markings in the lists:
True - marking is displayed.
False - marking is not displayed (default setting).
If several markings apply to one location, the most important information is displayed. For
instance, if a tool is locked, and at the same time, the "Tool position" and the "Reference
direction holder angle" for this tool do not match, then a red cross is displayed for locked. The
yellow triangle for the conflict cannot be seen.
Entries Meaning
ShowSymbolActivePlace Marking of the magazine location at the machining position.
True - default setting applies for the "Turret" magazine type.
False - setting for all other magazine types.
ShowSymbolActiveMultiToolPlace Marking of the multitool location at the machining position. Is
only displayed when the multitool is located in the spindle or
the tool holder.
True - default setting.
ShowSymbolLoadPlace Selection of the magazine location at the loading position.
True - default setting applies for all magazine types (except
Turret is true).
False - setting for the "Turret" magazine type.
ShowSymbolChangeInSpindlePlace Marking of the magazine location at the change position.
True - default setting applies for all magazine types (except
Revolver is true).
False - setting for the "Turret" magazine type.
ShowSymbolActiveTool Marking of the active tool.
False - default setting.
ShowSymbolProgrammedTool Marking of the follow-on tool.
True - default setting.
ShowSymbolActiveDNo Marking of the active cutting edge.
False - default setting.
ShowSymbolActiveDNoInTool Marking of the active tool by marking the active cutting edge.
True - default setting for configuration without magazine
management.
False - setting for configuration with magazine management.
ShowSymbolAcitveDlNo Marking of the active DL number.
True - default setting.
Tool management
12.2 Configuring the user interface
SINUMERIK Operate (IM9)
176 Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1
