Entry Meaning
TOOLTYPE_ALL_XXX The column setting applies to all tool types of a group. XXX stands for
the group number of the tool types. The hundreds position is used as the
group number, for example, TOOLTYPE_ALL_100 or TOOL‐
TYPE_ALL_200 etc.
TOOLTYPE_XXX The column setting applies to a particular tool type. XXX stands for the
number of the tool type.
EMPTY_MAG_PLACE The column setting applies to an empty magazine location. Empty mag‐
azine locations appear in a list sorted according to magazine.
Item Identifier of the list parameter.
See example: The column in which the magazine location type is dis‐
played is created with the identifier "MagPlaceType."
Tool parameter identifiers (Page 181)
Cutting edge parameter identifiers (Page 183)
Monitoring parameter identifiers (Page 186)
Magazine location parameter identifiers (Page 188)
DELETE_COLUMN Delete column.
INSERT_COLUMN Insert column.
Note
Independent of their programming, the entries are effective in the following sequence:
1. COLUMNX
2. DELETE_COLUMN
3. INSERT_COLUMN
Note
The Enabled entry does not apply for the "Tool Selection" window. The other entries apply.
Example 1: Configuring the magazine list - magazine location and tool location type
Note
The columns of the list configuration cannot be taken from the display in the user interface in
all cases because some columns are automatically inserted and therefore not included in the
count of the configuration.
Variant 1
Column 10 and column 11 are overwritten. If column 10 and column 11 do not exist, the new
columns will be added to the existing columns.
<LISTCONFIGURATION>
<!-- **** Magazine list *** -->
<SlTmToolmagazinForm>
Tool management
12.2 Configuring the user interface
SINUMERIK Operate (IM9)
178 Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1
