Data of the control components
Control components Data
NC data Machine data
Setting data
Option data
Global (GUD) and local (LUD) user data
Tool and magazine data
Protection zone data
R parameters
Zero offsets
Compensation data
Workpieces, part programs and subprograms
Standard and user cycles
Definitions and macros
With compensation data
● QEC - quadrant error compensation
● CEC - operation/angularity compensation
● EEC - leadscrew pitch / encoder error compensation
● It only makes sense to archive machine-specific compensation
data if the series start-up file is reloaded into the same control.
With compile cycles Compile cycles (*.elf) are displayed if compile cycles are available.
PLC data (including CP) OB (organization blocks)
FB (function blocks)
SFB (system function blocks)
FC (functions)
SFC (system functions)
DB (data blocks)
SDB (system data blocks)
HMI data, all
HMI data, selection:
Cycle storage Definitions and cycles
Texts User texts, alarm texts
Templates Individual templates, workpiece templates
Applications HMI applications, OEM applications
Engineering data Engineering data
Configuration Configurations, incl. display machine data
Help Help files
Version data Version data
Logs Error logs
User views Individually compiled tables with selected machine and setting data.
Dictionaries Dictionaries
Programs on local drive Programs contained in the user memory area of the CompactFlash
card.
