Page #479 background image
Attributes Meaning
Block start, type 1 or block end (all program levels, without intermediate
blocks)
Block start, type 2 or block end (all program levels, with intermediate blocks)
Block start, type 3 or block end (all main programs, without intermediate
blocks)
Block start or block end, block search (all program levels, without
intermediate blocks)
Geo axis start / direction change (2nd event)
Geo axis stop (2nd event)
Block start, type 2 (2nd event: all program levels, without intermediate
blocks)
Block end, type 2 (2nd event: all program levels, with intermediate blocks)
Block start, block advance, type 1 (2nd event)
OEM test event 1 (non-cyclic, block advance)
OEM test event 2 (non-cyclic, main run)
Activate/deactivate synchronized action
Synchronized action initiated (condition fulfilled)
Signaled alarm
Cancel softkey pressed
Program level change
Block end (Interpreter)
Trace end (last event!)
Start trace
WRTPR part program command
WRTPR part program command (block search)
Tool change
Cutting edge change
Tool change (block search)
Cutting edge (block search)
Start trigger initiated
Stop trigger initiated
Block end (block advance)
Block end (2nd event: Block search)
WRTPR part program command (block advance)
Tool change (block advance)
Cutting edge (block advance)
Event channel This means that the channel can be defined in SINUMERIK in which a specific
event occurs. For events which are not channel-specific, the field remains emp‐
ty.
Service and diagnostics
18.12 Trace
SINUMERIK Operate (IM9)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 465
